AD9912 Техническое описание и информация о продукте
Особенности и преимущества
- Частота внутреннего тактового сигнала 1 GSPS (частота выходного сигнала до 400 МГц)
- Интегрированный 14-разрядный ЦАП с быстродействием 1 GSPS
- 48-разрядное слово настройки частоты, разрешение по частоте 4 мкГц
- Дифференциальный компаратор HSTL
- Универсальный вход системного тактового сигнала с возможностью работы от кварцевого резонатора или внешнего опорного тактового сигнала
- Интегрированный малошумящий умножитель частоты REFCLK на основе ФАПЧ
- 2 канала SpurKiller
- Дополнительную информацию см. в техническом описании
Подробнее о продукте
AD9912 – это синтезатор прямого цифрового синтеза (DDS, direct digital synthesizer) с интегрированным 14-разрядным цифро-аналоговым преобразователем (ЦАП). AD9912 имеет разрядность слова настройки частоты (FTW, frequency tuning word) 48 бит, что позволяет синтезировать частоты с шагом не более 4 мкГц. Точность абсолютного значения частоты может поддерживаться за счет регулировки системного тактового сигнала ЦАП.AD9912 работает в промышленном температурном диапазоне от -40°C до +85°C.
Области применения
- Быстрый синтез частоты гетеродина
- Формирование тактового сигнала с малым дрожанием фазы и точной настройкой
- Испытательное и измерительное оборудование
- Базовые станции и контроллеры беспроводных систем
- Защищенная связь
- Системы с быстрой скачкообразной перестройкой частоты
Analog Devices AD9912 Даташит, AD9912 PDF, даташитов
Другие PDF | недоступен. | |
AD9912 Datasheet PDF : |

GENERAL DESCRIPTION
The AD9912 is a direct digital synthesizer (DDS) that features an integrated 14-bit digital-to-analog converter (DAC). The AD9912 features a 48-bit frequency tuning word (FTW) that can synthesize frequencies in step sizes no larger than 4 μHz. Absolute frequency accuracy can be achieved by adjusting the DAC system clock.The AD9912 also features an integrated system clock phase locked loop (PLL) that allows for system clock inputs as low as 25 MHz.
FEATURES
1 GSPS internal clock speed (up to 400 MHz output directly)
48-bit frequency tuning word with 4 μHz resolution
Differential HSTL comparator
Flexible system clock input accepts either crystal or external reference clock
On-chip low noise PLL REFCLK multiplier
2 SpurKiller channels
Low jitter clock doubler for frequencies up to 750 MHz
Single-ended CMOS comparator; frequencies of <150 MHz
Programmable output divider for CMOS output
Serial I/O control
Excellent dynamic performance
Software controlled power-down
Available in two 64-lead LFCSP packages
Residual phase noise @ 250 MHz
10 Hz offset: −113 dBc/Hz
1 kHz offset: −133 dBc/Hz
100 kHz offset: −153 dBc/Hz
40 MHz offset: −161 dBc/Hz
APPLICATIONS
Agile LO frequency synthesis
Low jitter, fine tune clock generation
Test and measurement equipment
Wireless base stations and controllers
Secure communications
Fast frequency hopping
